General
| Brand | MFZ |
|---|---|
| Power setting | 2,2 kW |
| Frequency Converter or Motor Relay? | Motor relay |
| Operating voltage | 3x400 Vac + N + PE(3 phase + Neutral + Protective Earth) |
| Motor voltage/ motor output | 400 Vac (3 phase) |
| Mains frequency | 50 Hz |
| Control voltage | 24 V |
| Max. load (per drive) | 2,2 kW (5,6 A) |
| IP protection class | n.a. |
| Max. humidity | 80%, non condensing |
| Housing | n.a. |
| Dimensions (WxHxD) | 225 x 140 x 55 mm |
| Fuse in mains | 10A |
| Plug on power cord | n.a. |
| Control panel on control box? | No |
| Display in control box? | No |
| Operating temperature | -10 ... +46 °C |
| Compatible model control | Marantec CS300, Marantec CS310, Marantec CS320 |
| Compatible drive model | Marantec MDF 05, Marantec MDF 20, Marantec MDF 30, Marantec MTZ-S 05, Marantec MTZ-S 20, Marantec MTZ-S 30, Marantec MTZ-S 50, Marantec STA 1, Marantec STAC 1, Marantec STAW 1, Marantec STAWC 1 |
