NOTE:
The remote SKX2WD functions on 433.92 MHz. There is also a Tedsen SF(x)2WD that looks just like it. That remote functions on 868 MHz however and is not compatible.
Programming your remote:
Set the DIP-switches in your new remote equal to the settings in your old remote. Don't have an old remote? Consult the settings found in your receiver.
When using both 1-channel and 2-channel remotes, it is necessary to set the last 2 DIP-switches (8 and 9) to 0 on all remotes and receivers used.
| Number of pushbuttons | 2 |
|---|---|
| Radio Frequency | 433MHz |
| Color of button | Black |
| Color of LED | Yellow or Amber |
| Radio code | Tedsen Teletaster SKX (433 DIP) |
| Number of channels | 2 |
| Rolling code? | No |
| Self learning? | Yes |
| Homelink compatibel? | No |
| Battery type | 23A / LR23 / MN21 12V Alkaline |
| Brand | Tedsen Teletaster |
