Important to know:
This receiver only works with Sommer SOMloq2 transmitters with the BeNeLux region code. The older SOMloq (without addition) transmitters and other region codes do not work on this receiver.
Bi-directional receiver 868 MHz (SOMloq2) with 2 channels, 40 memory locations expandable to 450 via the optional Memo memory module. Can work in both pulse and switching mode or for defined opening/closing. This receiver has an integrated antenna and optionally an additional antenna connection. Thanks to the hop function (repeater) of this SOMcom2 receiver, the range of all SOMloq2 receivers in the immediate vicinity is increased. Compatible with SOMlink.
Discover the new SOMcom2.1 receiver from SOMMER with antenna connection and additional programmable input. By default, this is a push button input, which can be programmed as a status input with the SOMlink S2.You can easily request the status of your garage door or gate with the Pearl Status & SOMtouch+ transmitters. The LED light on these transmitters indicates the door position by lighting up green or red.
Does your automation not have a status output? Mount a door sensor (door contact) on your gate or garage door and connect it to your SOMcom2.1. The LED of the Pearl Status or SOMtouch+ lights up green when your access is closed, and red when it is still open.
This receiver is suitable for controlling 2 different functions. These can be two different doors or gates, but it is also possible to activate different inputs on your gate control. This allows you to open the gate completely, for example, but also to put it in a walking position.
| Radio Frequency | 868MHz |
|---|---|
| IP protection class | IP 30 |
| Radio code | Sommer SOMloq2 (128Bit AES) BeNeLux-code |
| Memory for number of transmitters | 40 |
| Housing material | ABS (Plastic) |
| Number of channels | 2 |
| Operating voltage | 12/24 V ac/dc |
| External Antenna connection | Optional extension |
| Homelink compatibel? | No |
| Number of (relay/transistor) outputs | 2 |
| Function of the output | Momentary (puls) |
| Brand | Sommer |
