General
| Compatible drive model | Marantec STA 1, Marantec STA 1-x-x x FU-I, Marantec STAC 1, Marantec STAW 1, Marantec STAWC 1 |
|---|---|
| EAN-code (13) | 4011805053142 |
| Brand | Marantec |
Opsteek adapter Marantec WA-S 25.4/SW32
Stub shaft adapter 32 mm hexagon/six-sided shaft to 1 inch (25.4 mm) with groove
Suitable for mounting a Marantec hollow shaft drive from the STA1 series onto a shaft with an outer diameter of 31.75 mm.
Dimensions (in mm):
Size A : 25.4
Size B : 32
Size C : 120
Size D : 40
Size E : 200
Size F : 85
The delivery includes:
Stub shaft with flange
Key for groove 6.35x6.35x100 mm DIN 6885 Form A
Adjusting ring 25.4 mm
mounting bolt
Article also known as:
31.75 axle adapter
1 1/4" axle adapter
Reducing shaft for Crawford hexagon shaft
Stub shaft - 32mm hexagon shaft
WA-S 25.4/SW32 25.4 mm stub shaft with SW32 flange adapter
WA-S 25,4/SW32 Steckwelle 25,4 mm mit Anflanschadapter SW32
Technical specifications:
Brand
Marantec
Art. number
8055550
Compatible for driver
Click on one of the drives below to view compatible products.
