General
| Compatible drive model | Marantec STA 1, Marantec STA 1-x-x x FU-I, Marantec STAC 1, Marantec STAW 1, Marantec STAWC 1 |
|---|---|
| EAN-code (13) | 4011805051674 |
| Brand | Marantec |
stub shaft Marantec WA-S 25.4/31.75 N
Stub shaft round shaft 1¼ inch (31.75 mm) to 1 inch (25.4 mm) with keyway
Suitable for mounting a Marantec hollow shaft drive from the STA1 series onto a shaft with an outer diameter of 31.75 mm.
Dimensions (in mm):
Size A: 25.4
Size B: 31.75
Size C : 120
Size D : 40
Size E: 200
Size F : 70
The delivery includes:
Drive shaft assembly with flange adapter
Key for drive key way 6.35x6.35x30 mm DIN 6885 Form A
Key for drive key way 6.35x6.35x100 mm DIN 6885 Form A
Adjusting ring 25.4 mm
Adjusting ring 31.75 mm
2 securing bolts
Article also known as:
31.75 axle adapter
1 1/4" axle adapter
Reducing axis 1.25 inch to 1 inch
Slip-on adapter - 1 1/4" axle
WA-S 25.4/31.75 N stub shaft 25.4 mm with flange adapter 31.75 mm with groove
WA-S 25,4/31,75 N Steckwelle 25,4 mm mit Anflanschadapter 31,75 mm mit Nut
Technical data
Brand
Marantec
Art. number
8050772
Compatible for driver
