Receiver RX2 DUAL Universal 2 channels (433Mhz/868MHz)

Properties:

The receiver for existing handheld transmitters. Can you no longer expand your existing system because the memory spaces are full? Do you want to use your existing handheld transmitters at a new location? Do you want to use multiple brands and types of handheld transmitters together? That's possible from now on!

Use the universal radio receiver RX2 DUAL with transmitters of all kinds of brands and frequencies: fixed or rolling code, AM or FM, 433 or 868 Mhz, it is all possible with this one device. You can even program transmitters from multiple manufacturers and different frequencies in one and the same receiver.

Compatible with:

, among others

Aperto

868MHz SOMLoq 1

Comunello

433MHz Rolling Code

Ditec

433MHz DIP-10 Fixed Code

Faac

433MHz & 868MHz SLH Rolling Code

JCM Technologies

433MHz Rolling Code

Marantec

433MHz & 868MHz MultiBit Fixed Code

Nice

433MHz FloR 52-Bit Rolling Code

Sommer

868MHz SOMLoq 1

Telcoma

433MHz Fixed Code

Technical data:

Brand

Type

RX2 DUAL

Number of relay outputs

Relay load

Potential free

Maximum relapse load

60Vdc (3A) 120Vac (2A)

Supply voltage

12-24 Vac/dc

Consumption

25mA idle / 50 mA Max.

Relay functions

Pulsive / Bi-stable / Timer (Seconds) / Timer (Minutes)

Frequency

433.92 / 868 MHz

Number of memory locations

250

Dimensions

55 x 70 x 20 mm

Operating temperature

-20º / +70ºC

Technical specifications

Radio Frequency	433MHz, 868MHz
Radio code	Beninca (fixed code), BFT 433 Rolling Code, Cardin S449 64Bit, Cardin S486 64Bit, Comunello Victor Rolling code, Ditec Fixed (DIP-10), Ditec Rolling Code, Entry Rolling code, Faac SLH (Self Learning Hopping code), Gibidi rolling code, Gibidi fixed code (DIP-10), Genius rolling code, Hormann Fixed Code, JCM Rolling code, Key Automation Fixed Code, Key Automation Rolling Code, Marantec Multi-Bit (40Bit), MFZ Multi-Bit (fixed code), Nice FLO-code, Nice FloR 52-Bit, Nice O-code (Opera) 72-Bit (Era One / Inti), Nice SMILO-code, Prastel EASYROLL (with ERPA), RDA KeeLoq, SEAV 12Bit fixed code (DIP-10), SEAV 18Bit fixed code, Somfy RTS, Sommer SOMloq (64Bit), Teleco RollingCode
Memory for number of transmitters	250
Housing material	ABS (Plastic)
Number of channels	2
Operating voltage	12/24 V ac/dc
External Antenna connection	Screw Terminal
Homelink compatibel?	No
Number of (relay/transistor) outputs	2
Function of the output	Momentary (puls)
Brand	HR Matic
