Receiver Cardin RQM486200 mini 2 channels 868 MHz

120,00
Add to Compare
Availability
In stock
  • Contact us for large amounts (100+)

  • Unlimited online support

Technical specifications:
Product. Nr.: S486 RXM 2CH
Brand: Cardin
Type: RQM486200
Frequency: 868.3MHz
Channels: 2
Code: Rolling code
Max number of remote controls: 300
Supply: 12/24 Vac-dc (Set Jumper)
Dimensions: 95 x 75 x 25 mm
IP: 20

Relais:
CH1 = NO CH2= NO/NC.

Compatible with the remote controls:
CARDIN S486 TXQ486100
CARDIN S486 TXQ486200
CARDIN S486 TXQ486300
CARDIN S486 TXQ486400
CARDIN S486 TXQ48640M
CARDIN S486 TXQPRO486-4
CARDIN S486 TXQPRO486-4A

Install remote controls:
- Self learning (from remote to remote) whether or no being close to a receiver.
- Can be programmed directly to receiver. To do this, check the manual of your control/drive/receiver.

 Download the information leaflet here. (EN-DU-FR-ES)

General

Radio Frequency 868MHz
IP protection class IP 20
Radio code Cardin S486 64Bit
Memory for number of transmitters 300
Materiaal behuizing ABS (Kunststof)
Number of channels 2
Operating voltage 12/24 V ac/dc
Homelink compatibel? No
Number of (relay/transistor) outputs 2
Brand Cardin
